Ok i've had an idea about a good marble mg. its an over under design with a slip tee for the stock.
on the first elbow would it be ok drill a hole to put a hose barb there. By doing this i can feed the airhose up to the marbles.
It would have a 3 in chamber with a sprinkler valve.
I made a diagram on ms paint took me a while to get it to jpeg made it in 5 mins so its kinda sloppy.
Marble mg theory
- pyromaniac
- Corporal 4
- Posts: 805
- Joined: Tue Feb 27, 2007 7:18 pm
- Location: MO
- Attachments
-
- diagram.jpg (3.62 KiB) Viewed 2900 times
Last edited by pyromaniac on Wed Mar 21, 2007 4:06 pm, edited 3 times in total.
- Legendpilot
- Private 4
- Posts: 66
- Joined: Wed Jan 03, 2007 5:52 pm
You could use Adobe Photoshop. -Lppyromaniac wrote:I made a diagram on ms paint but it says i can't add the bitmap. Is there a way to turn it into a jpeg?
- pyromaniac
- Corporal 4
- Posts: 805
- Joined: Tue Feb 27, 2007 7:18 pm
- Location: MO
Does that come standard on microsoft?
- FreakyShotGlass
- Specialist
- Posts: 114
- Joined: Fri Dec 02, 2005 6:34 pm
Photoshop doesn't come standard on Windows. You can use Paint to save a JPEG in the newer versions, under save as you should be able to change the file type under the filename.
-
- Staff Sergeant
- Posts: 1596
- Joined: Fri Dec 15, 2006 3:57 pm
- Location: maryland
- Has thanked: 3 times
- Been thanked: 9 times
uhm you do know that this will dump the chamber and will just create a very very brief blast of marbles. you might as well use a current spud gun and load it with a bunch of marbles
There is a design that has been tested and works, it's affectionately called the "Vogt" pattern, where the clip extends behind the barrel and get sucked out with the air. DR built one of these just 2 days ago.
http://www.spudfiles.com/forums/viewtop ... 435𐭓
http://www.spudfiles.com/forums/viewtop ... 435𐭓
"There isn't a problem in the world that can't be solved by the proper application of explosives"
- jackssmirkingrevenge
- Five Star General
- Posts: 26203
- Joined: Thu Mar 15, 2007 11:28 pm
- Has thanked: 569 times
- Been thanked: 344 times
Atlantis wrote:DR built one of these just 2 days ago.
This particular cannon was built back in October of 2005
Last edited by jackssmirkingrevenge on Tue Oct 25, 2011 10:07 am, edited 1 time in total.
hectmarr wrote:You have to make many weapons, because this field is long and short life
- zeigs spud
- Corporal 2
- Posts: 657
- Joined: Tue Apr 04, 2006 10:39 pm
that disighn has been made before -cough-me-cough- but the feeder is above the barrel and the mrbles will just fallright out. you have to have the feeder below the barrel.
- pyromaniac
- Corporal 4
- Posts: 805
- Joined: Tue Feb 27, 2007 7:18 pm
- Location: MO
zeig did you post it, and thanks for the help.
Ok, I have a question: does the Vogt pattern refer only to guns with the magazine 'behind' the barrel like that, or do guns with the magazine coming in at 90 degrees to the barrel (like Brian the Brain's marble machine gun) also work on the same principle?
Also, on the guns with the 90 degree magazine, does the mag have to be horizontal, or could it come up from below the barrel? Would there be enough suction to draw the ammo up out of the magazine?
Also, on the guns with the 90 degree magazine, does the mag have to be horizontal, or could it come up from below the barrel? Would there be enough suction to draw the ammo up out of the magazine?
